BMW Z4 E89 Factory Service Repair manual
This page provides complete access to the official Factory Workshop Manual (Service Manual) for the second-generation BMW Z4 Roadster (E89), covering all years from 2009 to 2016. The manual includes detailed, step-by-step instructions for diagnosing and repairing all systems, including petrol engines (N20, N52, N54, N55), the retractable hardtop mechanism, transmission service (manual and DCT), and full interactive electrical wiring diagrams. This is the essential resource for professional and DIY servicing.
Z4 E89 Full Workshop Manual
| General Information | Download |
| Electrical Component Locations | Download |
| Accessories & Equipment | Download |
| Body & Frame | Download |
| Brakes, Repair and Technical Data | Download |
| Driveline & Axles | Download |
| Electrical System | Download |
|
Engine N52 Workshop Manual 2009-2011 |
Download |
|
Engine N54 Workshop Manual 2009-2011 |
Download |
| Engine Performance | Download |
| HVAC Heating and Air Conditioning | Download |
| Lighting. Repair and Technical Data | Download |
| Maintenance and General Information | Download |
| Restraints | Download |
| Steering | Download |
| Suspension | Download |
| Transmission 6HP19Z/GS6-17BG/DG | Download |
| System Wiring Diagrams | Download |
| Z4 E89 Full Workshop Manual | Download |
Z4 E89 Complete Vehicle
| Introduction. Body | Download |
| Retractable Hardtop. Hydraulic System | Download |
|
Electrical System |
Download |
|
Bus Diagram |
Download |
|
Control Units Location |
Download |
| E89 Chassis and Suspension | Download |
| Electric Power Steering (EPS) | Download |
| System Overview | Download |
| System Components | Download |
| Principles of Operation | Download |
| Service Information | Download |
BMW Z4 E89 - Common Problems
1. Engine and intake
N20 (20i/28i)
- Timing chain stretching – characteristic cold diesel sound, timing errors.
- Oil filter housing cracks (OFHG) → oil leak onto the belt.
- Idle vibration due to worn engine mounts.
- Valvetronic problems – position sensor or motor.
N52 (sDrive23i / 30i / 35i)
- Oil leaks: valve cover, oil filter gasket.
- Hydraulic lifters – knocking when cold (especially early N52).
- Vanos valve, solenoids – timing errors, loss of power.
- Electric water pump – sudden failure, overheating.
N54 / N55 (35i / 35is)
- High-pressure pump (HPFP) (especially N54).
- Ignition coils and spark plugs – frequent replacement.
- Intake deposits (N54) → walnut blasting required.
- Wastegate rattle (N54) – turbine rattle.
2. Electrical
- Roof/hydraulic position sensor failure (electric cable breaks near the hinge).
- GWS (automatic transmission selector) – sometimes glitches.
- PDC parking sensors – rear sensors fail.
- Alternator voltage regulator – power surges at idle.
3. Transmission
ZF 6HP / 8HP automatic
- Noise when shifting → oil change required (despite "lifetime").
- Valve body: jerking when shifting 2→1 or 3→2.
Manual transmission
- Clutch release bearing.
- Worn transmission mount → vibration.
4. Suspension and steering
- Stabilizer bars – a common consumable.
- Front strut support bearings – crunching/knocking.
- EPS rack – play, clicking on bumps (very common on the E89).
- Worn lower control arm bushings → vibration when braking.
5. Body and interior
Water in the trunk – a problem with the ventilation valves.
Worn roof mechanism:
- clogged drains,
- roof position sensors,
- hydraulic cylinders leak over time.
Worn soft-touch coating – peeling.
6. Cooling
- The electric pump and thermostat are the weak point of all N52/N54/N55/N20 models.
- Cracks in the expansion tank.
- Overheating due to a faulty pump → emergency mode.
